Soundproof Energy Efficiency Big View Sliding Doors

Soundproof Energy Efficiency Big View Sliding Doors

$75-150 /Square Meter

Contact Now

Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: SHENZHEN

Description

Product Attributes

Model No.: WD-SD034

Brand: Wendou

Warranty Service: More Than 5 Years

Place Of Origin: China

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: China

Supply Ability: 10000㎡/month

Certificate: NFRC/AS2047

HS Code: 7610100000

Port: SHENZHEN

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF,EXW

Product Description

Soundproof Energy Efficiency Big View Sliding Doors

1. Design Advantages

Minimalist Narrow Bezel Design:Utilizing ultra-narrow aluminum alloy frames (such as 1.2-2.0mm thick 6063-T5 aerospace-grade aluminum) paired with large tempered glass panels (single panel width can exceed 3 meters), it achieves a panoramic view. For example, a four-panel sliding door combination can cover an entire wall, visually eliminating spatial barriers and enhancing the sense of openness when connecting the indoor living room and outdoor courtyard.

Hidden Track System:The embedded track design reduces floor protrusion, and paired with silent rollers, it ensures both safety and enhances overall aesthetics. Some high-end products use recessed tracks for barrier-free access, suitable for villas, retirement communities, and other similar settings.

Diverse Opening Methods:Aluminum Sliding Doors support 2-track, 3-track, and 4-track configurations, enabling multi-pane linkage or fixed window combinations. For example, a 3-track design allows two doors to open simultaneously, balancing ventilation efficiency and spatial flexibility.

2. Material Characteristics

High-strength aluminum alloy frame

Broken bridge thermal insulation technology: PA66 nylon thermal break strips block heat conduction, combined with double-glazed windows (e.g., 5mm+12A+5mm configuration), reducing energy consumption by over 30%, meeting green building standards.

Weather resistance: The aluminum alloy surface is anodized or fluorocarbon coated, resistant to UV rays and corrosion, suitable for humid or coastal environments. For example, the profile wall thickness reaches 2.0mm, capable of withstanding strong wind pressure (e.g., typhoon areas).

Double-glazed configuration

Sound insulation and noise reduction: The insulated layer is filled with argon gas, combined with glass of different thicknesses (e.g., 5mm+6mm), effectively blocking 30-45 decibels of noise, suitable for airports, schools, or areas near busy commercial districts.

Safety protection: Tempered glass has strong impact resistance, breaking into blunt-angled pieces; some products offer laminated glass (PVB interlayer) for further enhanced security.

Energy-saving and environmentally friendly: Low-E coated glass reflects infrared rays, reducing air conditioning load, and combined with a double-glazed structure, it provides warmth in winter and coolness in summer.

Sealing and Hardware System

Multi-layer sealing design: Utilizes EPDM rubber sealing strips, combined with both weatherstripping and rubber strips for double protection, preventing rainwater and dust penetration.

High-end hardware accessories: Imported silent pulleys, anti-pry locking points, concealed handles, etc., enhance smooth operation and security.

3. Application Scenarios

Residential Sector

Balcony/Terrace: Connects indoor and outdoor spaces, improving lighting and ventilation efficiency while isolating rainwater and noise. For example, coastal villas feature wind pressure-resistant designs to withstand typhoons.

Kitchen and Dining Room: Open-plan design enhances interaction, and double-glazed windows block cooking fumes and odors.

Bedroom and Bathroom: Frosted glass options ensure privacy, and magnetic locks enable silent operation.

Commercial Spaces

Hotels/Clubs: Large sliding doors create pillarless banquet halls, enhancing spatial flexibility. For example, a single 3-meter-wide door can be concealed within the wall, enabling rapid scene transitions.

Office Buildings: An electric intelligent system links air conditioning and lighting, with sensors for energy-saving management.

Retail Stores: Transparent glass displays merchandise, attracting customers while insulated glass reduces air conditioning load.

Special Applications:

Recording Studios/Cinemas: High sound insulation (STC rating of 45 or higher) meets professional acoustic requirements.

Medical Facilities: Antibacterial coated glass and sealed design prevent cross-infection.

Industrial Plants: Explosion-proof glass and reinforced frames adapt to high-risk environments.

4. Customization Options

Size and Structure: Aluminum Doors support non-standard customization, with widths exceeding 6 meters and heights exceeding 3 meters, adapting to irregularly shaped spaces (such as curved balconies).

Selectable Track Quantity (2 to 4 tracks) allows for multi-door linkage or fixed window combinations.

Function Upgrades:

Intelligent Control: Integrated motor drive, remote control/APP operation, and automatic closing function with weather sensors.

Safety Features: Added fingerprint lock, anti-pinch sensor, and emergency escape device. Decorative Details: Features include concealed handles, recessed curtain boxes, and anti-collision strips.

Custom Exterior Design

Frame Colors: Custom Aluminium Doors are available in standard colors such as matte black, champagne gold, and silver-gray, with options for wood grain transfer or special coatings.

Glass Types: Clear, grey, blue, and coated glass are available to suit various style preferences.

Energy Efficiency Certifications: Products meet NFRC standards, contributing to green building certifications (such as LEED and BREEAM).
