Custom Commercial Security Double Layer Aluminium Door

Custom Commercial Security Double Layer Aluminium Door

$75-150 /Square Meter

Frame material	Aluminum Alloy
Contact Now

Payment Type: L/C,T/T,Paypal
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: Shenzhen,Guangdong

Description

Product Attributes

Model No.: WD-CD021

Brand: Wendou

Warranty Service: More Than 5 Years

Place Of Origin: China

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: Made in China

Supply Ability: 10000㎡/month

Certificate: NFRC/AS2047

HS Code: 7610100000

Port: Shenzhen,Guangdong

Payment Type: L/C,T/T,Paypal

Incoterm: FOB,CFR,CIF,EXW

Product Description

Customized Commercial Security Double-Layer Aluminum Doors

1. Structural Features: Modular Frame and Multi-Layer Protection Design

Customized commercial security double-layer aluminum doors utilize a modular frame structure, consisting of a top rail, bottom rail, hinge stile, and lock stile, with double-layered glass or composite panels embedded in the middle.

The core design logic includes:

Double-layer structure enhances security: The outer layer of the Aluminum Commercial Doors is a high-strength aluminum alloy frame, while the inner layer can be made of tempered glass, laminated glass, or bulletproof panels, forming a physical barrier to effectively resist violent attacks. For example, bulletproof aluminum doors use a double-layer design to withstand handgun bullet impacts.

Concealed hinges and multi-point locking system: The hinges are hidden inside the frame, combined with multi-point locks (such as 3-5 locking points) and anti-pry bolts, significantly improving anti-pry performance.

Flexible door configuration: Supports single doors, double doors, mother-daughter doors, or folding doors to adapt to different space requirements. For example, PRL aluminum doors offer single-acting opening options such as center pivot, eccentric pivot, or butt hinge.

Adjustable sill design: The bottom track height is adjustable (e.g., a 10-inch bottom track meets ADA accessibility standards), and some models are equipped with aluminum sills and weatherstripping for windproofing, waterproofing, and sound insulation.

2. Material Advantages: High Strength, Corrosion Resistance, and Lightweight

The core material of double-layer aluminum doors is 6063-T5 or 6061-T6 aluminum alloy, combined with tempered glass or composite panels, offering significant advantages:

Impact Resistance and Bulletproof Performance: The aluminum alloy frame provides structural support, and the inner glass or panels can be upgraded to bulletproof level (e.g., UL 752 standard).

Corrosion Resistance and Long Lifespan: The aluminum surface is anodized or powder-coated to form a protective layer, resisting harsh environments such as salt spray and acid rain, with a lifespan exceeding 20 years. Steel components (such as locks) are made of stainless steel or galvanized to prevent rust.

Lightweight and Easy to Maintain: Aluminum alloy has only one-third the density of steel, reducing the weight of the door and lowering the load on the building structure. At the same time, aluminum is less prone to deformation, resulting in low maintenance costs and making it suitable for high-frequency use scenarios.

Optimized Thermal Performance: Through thermal break technology, polyamide thermal insulation strips are embedded inside the aluminum profile to block heat conduction and reduce air conditioning energy consumption. For example, Metal Technology's System 10-35 Hi+ door system has a U-value as low as 0.93 W/(m²·K) (triple-glazed configuration).

Environmentally Friendly and Recyclable: Aluminum has a recycling rate of over 95%, and its production energy consumption is only one-fifth that of steel, meeting LEED green building certification requirements.

3. Applicable Buildings

Full Coverage of High-Security Scenarios Double-layer aluminum doors, with their security and flexibility, are widely used in the following scenarios:

Commercial Retail: Shopping malls, specialty stores, bank entrances, requiring both merchandise display and anti-theft functions. For example,

Public and Institutional Buildings: Schools, hospitals, government office buildings, requiring compliance with high-traffic access and security regulations. These scenarios often feature bulletproof glass, escape levers, and multi-point locking systems, meeting PAS24 or UL safety standards.

Industrial and Warehousing: Entrances to factories and logistics centers require protection against heavy equipment impacts and unauthorized intrusion. Some models utilize thickened aluminum profiles (such as 4-inch wide mullions) and industrial-grade locks to withstand harsh environments.

High-Risk Locations: Jewelry stores, vaults, data centers, etc., require customized bulletproof and explosion-proof doors.

4. Customization Options: Limitless Possibilities from Size to Smart Features

Double-layer aluminum doors offer a high degree of customization. Key options include:

Size and Shape: Custom Aluminium Doors support non-standard sizes (e.g., width up to 8 feet, height up to 10 feet), curved, right-angled, or irregular designs to suit special building structures.

Surface Treatments:

Anodizing: Available in clear, black, champagne, etc., scratch-resistant and long-lasting color.

Powder Coating: Over 50 colors available (e.g., wood grain, metallic paint), with RAL color chart customization supported.

Glass and Sheet Configuration:

Functional Glass: Low-emissivity glass reduces UV radiation, laminated glass is explosion-proof, and electrochromic glass adjusts light transmittance.

Composite Sheets: Optional steel plates, bulletproof fiberboard, or stainless steel plates enhance protection levels.

Hardware System:

Locks: Multi-point locks, electronic locks, biometric locks, or independent locking systems enhance security.

Door Opening Methods: Manual, automatic sensor, floor spring, or electric sliding rails to adapt to different flow requirements.

Auxiliary Devices: Windproof strips, door closers, escape push rods, anti-pry bolts, and viewing windows (for solid doors).

Intelligent Integration: Can be embedded with facial recognition, temperature monitoring, or air quality sensors, linking with building management systems (BMS) to achieve smart access control. For example, some models support remote monitoring and anomaly alarm functions.
