Hot Sale Modern Interior-Exterior Aluminum Wall Panel

Hot Sale Modern Interior-Exterior Aluminum Wall Panel

$75-150 /Square Meter

Material	Aluminum
option
Contact Now

Payment Type: L/C,T/T,Paypal
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: shenzhen

Description

Product Attributes

Model No.: WD-CWL014

Brand: Wendou

Variety: Curtain Walls

After-sales Service: Return And Replacement, Onsite Installation, Online Technical Support, Onsite Training, Onsite Inspection

Application Scenario: Exterior, Entry, Other, Courtyard, Farmhouse, Sports Venues, Hotel, Apartment, Leisure Facilities, Villa, Office Building, Supermarket, Hospital, Warehouse, School, Workshop, Mall, Park

Place Of Origin: China

Screen Netting Material: Aluminum Alloy/Stainless steel/Fiberglass

Main Material: Aluminum alloy+Glass+Accessories

Glass: Tempered glazing+Laminated glazing+Low-E glazing+Reflective glazing+Frosted glazing

Color: Customized based on your needs

Hardware: Germany brand/Chinese brand/American brand

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: Made in China

Supply Ability: 10000㎡/M

Certificate: NFRC/CE/AS2047

HS Code: 7610100000

Port: shenzhen

Payment Type: L/C,T/T,Paypal

Incoterm: FOB,CFR,CIF,EXW

Product Description

Hot Sale Modern Interior-Exterior Aluminum Wall Panel

Aluminum alloy wall panels have become a core material for modern interior and exterior architectural decoration due to their lightweight, corrosion-resistant, and design flexibility.

1. Aluminum Curtain Wall Exterior Construction

Flat and Custom-Shaped Designs

Standard flat panels: 1-4mm thick, with a smooth surface, are suitable for large wall coverings, such as commercial building facades or interior partitions.

Curved Surfaces: Through CNC bending or stamping processes, customizable three-dimensional shapes such as wavy, curved, and diamond-shaped panels can be created to enhance the sense of space dynamics. For example, 3D curved wall panels in shopping mall atrias can guide pedestrians' gaze and enhance the visual experience.

Perforated and Hollow Panels: Laser cutting technology creates precise perforations, creating light-transmitting or ventilation effects. Wall panels with a perforation ratio of 5%-30% are often used for optimizing indoor acoustics or building ventilation.

Surface Treatment

Spraying: Fluorocarbon fiber (PVDF) paint offers over 15 years of weather resistance and high color saturation. Powder coating offers low cost and is suitable for quick renovation projects. Anodizing: Creates an oxide film, increasing surface hardness (reaching HV400 or above) while imparting a metallic luster, making it suitable for high-end interior decoration.

Wood Grain Transfer: Uses thermal transfer technology to simulate the texture of real wood, achieving a natural, maintenance-free look.

Installation System: Snap-on Connection: Concealed snap-on design enables nail-free installation, enhancing aesthetics.

Modular Assembly: Individual wall panels can measure up to 1.2m x 2.4m, reducing the number of joints and improving construction efficiency.

2. Aluminum Frames For Curtain Wall Material Type: Aluminum Alloy Base Material

Grade Selection: 6063-T5 aluminum alloy (tensile strength ≥160MPa) is suitable for general applications; 6061-T6 aluminum alloy (tensile strength ≥240MPa) is suitable for high-rise buildings or typhoon-prone areas.

Alloying Elements: Magnesium and silicon are added to enhance corrosion resistance, while copper is added to enhance strength.

Composite Structure

Aluminum Honeycomb Panel: Composed of 0.5mm thick aluminum face sheets and an aluminum honeycomb core, it weighs only 6-8kg/m² and offers a sound insulation rating of 32dB, making it suitable for acoustically sensitive spaces such as theaters and conference rooms.

Aluminum-Plastic Panel: The interlayer is polyethylene (PE) or fire-resistant polyethylene (FR). Costs are 30% lower than pure aluminum panels, but requires B1 fire resistance certification.

Functional Coating

Self-Cleaning Coating: Nano-titanium dioxide coating decomposes organic matter, reducing cleaning frequency and making it suitable for heavily polluted areas.

Insulating Coating: Reflects infrared radiation, lowering wall temperatures by 10-15°C and reducing air conditioning energy consumption.

3. Aluminum Glass Curtain Wall Applicable Regions and Building Types

Climate Adaptability

Hot and humid regions: A fluorocarbon coating combined with an aluminum honeycomb structure provides corrosion resistance and thermal insulation, suitable for Southeast Asia and southern China.

Cold regions: A polyurethane (PU) foam interlayer is added to enhance thermal insulation (thermal conductivity ≤ 0.024W/m·K). Suitable for regions such as Northern Europe and Canada. Coastal Areas: Use 5052-H32 aluminum alloy (salt spray resistance test ≥ 1000 hours) to prevent chloride ion corrosion.

Architectural Applications

Commercial Buildings: Exterior facade decoration and interior atrium partitions, such as in shopping malls and office buildings.

Public Facilities: Acoustic wall panels or wayfinding systems in subway stations and airports.

Residential Projects: Villa exterior walls and balcony railings, combined with wood grain transfer technology to enhance living quality.

4. Functional Benefits: Dual Enhancement of Performance and Efficiency

Structural Performance

Lightweight: Density of 2.7g/cm³ is only 1/3 that of steel, reducing building loads and making it suitable for renovation of existing buildings.

Wind Pressure Resistance: 1.5mm thick wall panels can withstand wind pressure of 1.2kPa, meeting high-rise building standards.

Environmental Benefits

Energy Savings: The thermal insulation coating and hollow structure reduce building energy consumption by 20%-30%, meeting LEED or green building standards.

Recyclable: The aluminum alloy recycling rate reaches 95%, reducing resource consumption.

Economical

Lifecycle Cost: While the initial unit price is higher than tiles or paint, maintenance costs are lower, resulting in a lower total cost over a 30-year lifecycle.

Construction Efficiency: Modular installation shortens construction time by 30% and reduces labor costs.
