Wall Decoration Aluminum Panel Cladding

$75-150 /Square Meter

Material	Aluminum Alloy
Contact Now

Payment Type: L/C,T/T
Incoterm: CFR,CIF,FOB,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: shenzhen

Description

Product Attributes

Model No.: WD-CWL018

Brand: Wendou

Variety: Curtain Walls

Warranty Service: More Than 5 Years

Place Of Origin: China

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: China

Supply Ability: 10000㎡/M

Certificate: NFRC/CE/AS2047

Port: shenzhen

Payment Type: L/C,T/T

Incoterm: CFR,CIF,FOB,EXW

Product Description

Wall decoration aluminum panel cladding is a building exterior wall decoration system that uses aluminum alloy panels as its core, combined with advanced processing technology and surface treatment techniques. Its modular design enables efficient installation, combining functionality and artistry, making it an important choice for modern building facade design.

1. Appearance and Structure

Aluminum panel cladding presents diverse appearance characteristics. Panels can be processed into flat, curved, folded, or irregular shapes, creating dynamic light and shadow effects through processes such as punching, carving, and hollowing. Surface treatment technologies give it rich textures: fluorocarbon spraying achieves matte, high-gloss, or metallic finishes; stone and wood grain transfer technology simulates natural material textures; and anodizing forms a colored oxide film. Panel thickness is typically 1.5-4.0mm, and it is fixed to the keel frame using angle brackets, bolts, or back-bolt systems to form continuous or discontinuous decorative surfaces. Some projects adopt a double-layer curtain wall structure, with an inner layer containing ventilation chambers, and an outer layer combining aluminum panels with materials such as glass and stone to create a layered facade effect.

2. Material Types

The core material is aluminum alloy sheet, commonly used grades include AA1100, 3003, 5005, and 6063. Among them:

AA1100: Pure aluminum series, excellent processing performance, suitable for complex-shaped curtain walls;

3003/5005: Aluminum-manganese alloy, moderate strength, outstanding corrosion resistance, widely used in coastal areas;

6063: Aluminum-magnesium-silicon alloy, strengthened through heat treatment, balancing mechanical properties and weldability, suitable for structural load-bearing components.

Surface coatings are divided into three main categories:

Fluorocarbon coating (PVDF): Contains more than 70% fluoropolymer resin, resistant to ultraviolet rays, acid rain, and chemical corrosion, with a service life exceeding 20 years;

Powder coating: Solvent-free, environmentally friendly coating, high color saturation, but slightly inferior weather resistance to fluorocarbon;

Anodizing: Forms an oxide film through electrolysis, natural color, but only suitable for indoor or low-pollution environments.

3. Applicable Regions and Building Types

Aluminum panel curtain walls boast exceptional adaptability:

Climate Conditions: Remains stable within a temperature range of -50℃ to +80℃. Low-temperature resistant alloys are required in frigid regions, while enhanced weather resistance coatings are necessary in tropical areas.

Geographical Environment: 3003/5005 alloys with fluorocarbon coatings are preferred in coastal areas, while Curtain Wall Aluminum resists salt spray corrosion. Powder coatings can be used in arid inland areas to reduce costs.

Building Types:

Commercial Buildings: Shopping malls, office buildings, and other modern spaces utilize irregularly shaped aluminum panels combined with lighting to create a technological atmosphere.

Cultural Facilities: Museums, theaters, and other venues employ stone-textured aluminum panels to balance aesthetics with historical depth.

Transportation Hubs: Airports, subway stations, and other large-span spaces leverage the lightweight properties of aluminum panels to reduce structural load.

Residential Projects: High-end apartments utilize wood-grain transfer aluminum panels to simulate natural materials and enhance living quality.

4. Functional Benefits

Protective Performance:

Weather Resistance: Fluorocarbon coating resists UV rays, acid rain, and industrial pollution, extending building lifespan;

Fire Resistance: Class A non-combustible material, meeting high-rise building fire safety standards;

Self-Cleaning: The smooth surface of the Aluminum Curtain Wall reduces dust adhesion; rainwater washing keeps it clean.

Energy Saving and Environmental Protection:

Thermal Insulation: Hollow structure or aluminum panel curtain wall filled with insulation cotton has a thermal conductivity coefficient as low as 0.5 W/(m·K);

Recyclability: Aluminum alloy has a recycling rate of over 95%, meeting green building standards;

Lightweight: Density is only 1/3 that of steel, reducing foundation structural costs.

Aesthetic Value:

Customizable Colors: Any color from the RAL color chart is available, supporting special effects such as gradients and brushed metal finishes;

Dynamic Design: The Aluminum Glass Curtain Wall uses parametric design to achieve complex shapes such as curved surfaces and twists, creating iconic buildings;

Light and Shadow Interaction: Perforated aluminum panels combined with lighting create a dynamic visual effect at night.

5 Typical Cases

Shanghai Tower: Utilizes a combination of double-layered glass curtain walls and aluminum panels, with the outer aluminum panel forming a spiraling, three-dimensional shape through parametric design;

Marina Bay Sands Hotel, Singapore: The roof uses gold fluorocarbon-coated aluminum panels, creating a contrast between solid and void with the glass curtain wall;

Harbin Grand Theatre: The white aluminum panel curtain wall simulates the texture of ice and snow, blending seamlessly with the surrounding environment.

Aluminum panel curtain walls, through material innovation and process upgrades, achieve a unity of functionality and artistry, becoming the preferred solution for modern building facade design. Their modular installation, long lifespan, and low-carbon environmental characteristics further align with the demands of a sustainable development era.
