Security Aluminium Vertical Folding Door

Security Aluminium Vertical Folding Door

$75-150 /Square Meter

Frame material	Aluminum Alloy
option
Contact Now

Payment Type: T/T,L/C
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: SHENZHEN

Description

Product Attributes

Model No.: WD-FD023

Brand: Wendou

Warranty Service: More Than 5 Years

After-sales Service: Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection

Engineering Solution Capability: Graphic Design, 3d Model Design, Total Solution For Projects

Application Scenario: Hotel, Villa, Apartment, Office Building, Hospital, School, Supermarket, Warehouse, Workshop

Design Style: French, Chinese, European, Modern, Traditional, Farmhouse, Industrial

Place Of Origin: China

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: Made in China

Supply Ability: 10000㎡/month

Certificate: NFRC/AS2047

HS Code: 7610100000

Port: SHENZHEN

Payment Type: T/T,L/C

Incoterm: FOB,CFR,CIF,EXW

Product Description

Security Aluminium Vertical Folding Door is an aluminum vertical folding door designed for security needs. It uses a high-strength aluminum alloy frame and multi-layer safety glass, and can be opened and closed quickly through a vertical folding structure. Its core function is to take into account spatial flexibility and safety protection through a multi-locking point anti-theft system + impact-resistant materials. It is suitable for scenes that require efficient separation and safety.

Aluminum Folding Doors Core advantages and features

Excellent security

Anti-theft locks: Equipped with multi-locking point anti-theft lock cylinders, in line with PAS 24 security standards, the anti-pry performance is improved by 50%, and it can resist violent opening.

Impact-resistant glass: Standard 5mm tempered glass (impact strength ≥120J), optional laminated glass (impact strength ≥300J) to prevent shattering and splashing.

Anti-pry design: The connection between the door frame and the wall uses hidden expansion bolts, with a spacing of ≤300mm and a tensile pull-out force of ≥2000N.

Space and visual optimization

Vertical folding: The door leaf can be folded vertically upwards, and the space occupied is reduced by 90% after it is fully opened, which is suitable for scenes with narrow passages or high ceilings.

Transparent design: The width of a single glass can reach 1200mm, and the height can be customized to 3000mm. With Low-E glass, the light transmittance is ≥85%, and the field of vision is wide.

Physical properties

Wind pressure resistance: The wall thickness of the aluminum alloy profile is ≥2.0mm, and the wind pressure resistance level reaches level 9 (wind speed ≥24.4m/s), which is suitable for coastal areas.

Heat insulation and energy saving: The broken bridge aluminum structure is matched with hollow glass (5mm+12A+5mm), the heat transfer coefficient K value is ≤2.0W/(m²·K), and energy saving is 30%.

Sound insulation and noise reduction: The sound insulation performance reaches RW=35dB, which effectively blocks traffic noise.

Customized Waterproof Aluminum Folding Doors Durability and maintenance

Material life: The aluminum alloy surface is fluorocarbon sprayed, the corrosion resistance reaches AAMA 2605 standard, the salt spray test is ≥2000 hours, and the outdoor service life exceeds 20 years.

Hardware system: The hinge is made of 304 stainless steel, with a load-bearing capacity of ≥150kg/set and a folding life of ≥100,000 times; the pulley group is equipped with high-speed rail-grade bearings, and the push-pull resistance is ≤20N.

Tempered Glass Bifold Doors Application scenarios

Commercial security scenarios

Bank vaults: Multi-locking point anti-theft system and impact-resistant glass to prevent violent intrusion.

Jewelry stores: Vertical folding design quickly closes the display cabinet area to ensure the safety of valuables.

Industry and logistics

Warehouse isolation area: Wind pressure-resistant design to cope with forklift operation airflow, with electric opening system, efficiency increased by 40%.

Factory workshop: Dustproof and soundproof performance meets the needs of precision manufacturing, and noise is reduced by 20dB.

High-end residences

Villa courtyards: Vertical folding doors replace traditional sliding doors to achieve seamless connection between indoor and outdoor spaces, while ensuring privacy and safety.

Balcony window sealing: Windproof and waterproof design to cope with extreme weather, with intelligent sensing system to enhance living experience.

Public facilities

Hospital isolation area: Air tightness meets medical standards to prevent cross infection.

School laboratory: corrosion-resistant materials and easy-to-clean surfaces, suitable for chemical experimental environments.
