Aluminum Tilt Turn Casement Doors

$75-150 /Square Meter

Contact Now

Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: SHENZHEN

Description

Product Attributes

Model No.: WD-LSD023

Brand: Wendou

Warranty Service: More Than 5 Years

Place Of Origin: China

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: Made in China

Supply Ability: 10000㎡/month

Certificate: NFRC/AS2047

HS Code: 7610100000

Port: SHENZHEN

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF,EXW

Product Description

Aluminum Tilt and Turn Casement Doors

1. Structural Features

Aluminum tilt and turn casement windows and doors combine two opening methods: casement and tilt-in, with function switching achieved by rotating the handle:

Casement Mode:

The door leaf opens outwards on side hinges, with a maximum opening angle of up to 90°, providing unobstructed passage, suitable for emergency exits or moving large items. Its multi-point locking design (such as the distribution of hardware locking points) ensures a tight fit between the door leaf and frame when closed, achieving airtightness above national standard level 8.

Tilt-in Mode:

The upper part of the door leaf tilts inwards at an angle of 10-15°, creating a safe ventilation opening. This design prevents rainwater from entering and prevents children from climbing and falling, complying with the European EN 14351-1 safety standard. In the tilt-in state, the weight of the door leaf is borne by the hinges, preventing deformation during long-term use.

Hardware System:

Uses hardware from brands such as German ROTO or SIEGENIA, including anti-misoperation handles, adjustable hinges (load capacity up to 150kg), and multi-point locking devices. The hinges have built-in dampers for soft closing of the door leaf, reducing impact noise.

2. Material Advantages

Corrosion Resistance:

The main frame of the Aluminum Doors uses 6063-T5 aluminum alloy profiles, with the surface treated by anodizing (thickness ≥15μm) or powder coating (film thickness 60-120μm), which can resist salt spray and acid rain corrosion, with a service life of over 30 years. Experimental data shows no significant corrosion within 10 years in high-humidity coastal environments.

Thermal Performance:

Aluminum Lift And Slide Doors can be optionally equipped with thermal break strips (PA66+GF25), reducing the thermal conductivity coefficient to 1.8-3.5W/(m²·K), meeting the energy-saving requirements of passive houses. Combined with Low-E double-glazed glass (such as a 5+12A+5+12A+5 triple-glazed, double-cavity structure), the overall window K-value can be as low as 0.8W/(m²·K), significantly reducing air conditioning energy consumption. Structural Strength:

The profile wall thickness is 1.8-3.0mm, and the moment of inertia of the main load-bearing members reaches over 12cm⁴, providing wind pressure resistance up to level 9 (P3≥5.0kPa), making it suitable for high-rise buildings and typhoon-prone areas.

3. Applicable Building Types

High-end Residences:

Commonly used in projects such as villas and large apartments to create large, transparent facades (e.g., single sash size up to 1500mm×3000mm), combined with a narrow frame design (frame and sash visible width ≤55mm), enhancing natural light and viewing experience.

Commercial Buildings:

Hotels and office buildings utilize its inward-tilting ventilation function for natural ventilation, reducing energy consumption from mechanical ventilation. At the same time, the multi-point locking and sealing design effectively blocks outdoor noise (noise reduction of 35-40dB), meeting the sound insulation standards of five-star hotels.

Public Facilities:

Hospitals and schools use its anti-finger trapping design (hidden hinge structure) and easy-to-clean features (no dead corners), meeting public health and safety requirements.

4. Customization Options

Size and Shape:

Custom Aluminium Doors support non-standard size customization (minimum width 300mm, maximum height 3500mm), and can be made into curved, corner, and other irregularly shaped doors and windows to adapt to complex building facades.

Surface Treatment:

Offers over 20 surface effects, including wood grain transfer (such as golden oak, teak wood grain), and brushed metal (champagne gold, titanium gray), to match different decoration styles.

Glass Configuration:

Optional single/double Low-E glass, laminated safety glass, electrochromic glass, etc., to achieve privacy protection, intelligent dimming, and other functions.

Smart Integration:

Can be equipped with electric window openers, rain and wind sensors, fingerprint locks, and other smart modules, enabling remote operation via mobile app or voice control, improving convenience.
