Energy Efficient Aluminum Lift Door Doors for Villa

Energy Efficient Aluminum Lift Door Doors for Villa

$75-150 /Square Meter

Contact Now

Payment Type: L/C,T/T,Paypal
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: SHENZHEN

Description

Product Attributes

Model No.: WD-LSD024

Brand: Wendou

Warranty Service: More Than 5 Years

Place Of Origin: China

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: Made in China

Supply Ability: 10000㎡/month

Certificate: NFRC/AS2047

HS Code: 7610100000

Port: SHENZHEN

Payment Type: L/C,T/T,Paypal

Incoterm: FOB,CFR,CIF,EXW

Product Description

Energy-Efficient Aluminum Lift Door for Villas

1. Definition and Core Functions

The energy-efficient aluminum lift door is a sliding door system designed specifically for villas and high-end residences. Through a combination of vertical lifting and horizontal sliding (some models support multi-track sliding), it achieves large, transparent facades while integrating high-efficiency thermal insulation, sound insulation, waterproofing, and wind pressure resistance. Its core advantage lies in significantly reducing building energy consumption and improving living comfort through innovative materials and structural design.

2. Appearance and Structural Features

Minimalist Design:

The Aluminum Doors feature a narrow frame design (middle frame width can be as low as 25mm), reducing visual obstruction and maximizing glass area (single pane glass area can reach over 6㎡), creating a transparent and bright effect. The door panel is flush with the frame, with clean and smooth lines, suitable for modern, industrial, or natural style architecture.

Modular Structure:

The main frame of the Best Aluminium Doors is constructed from high-strength aluminum alloy profiles. Thermal break strips (PA66+GF25) divide the profiles into inner and outer layers, blocking heat conduction. The door panel is filled with insulation material (such as polyurethane foam) to further enhance thermal insulation performance.

Hidden Hardware:

The lifting mechanism, pulley system, and locking points are hidden within the profile cavity, with no exposed screws or handles, enhancing aesthetics. Some models are equipped with an electric lifting system, allowing door opening and closing to be controlled via remote control or mobile app.

3. Material Advantages

High-Efficiency Thermal Insulation:

Thermal break aluminum profiles combined with Low-E double-glazed glass (such as a 5+12A+5+12A+5 triple-glazed, double-cavity structure filled with argon gas), the overall window U-value can be as low as 0.8W/(m²·K), saving more than 50% energy compared to ordinary aluminum alloy doors and windows, meeting passive house standards.

Wind Pressure Resistance and Durability:

The profile wall thickness reaches 2.0-3.0mm, and the moment of inertia of the main load-bearing members exceeds 15cm⁴, achieving a wind pressure resistance rating of level 9 (P3≥5.0kPa), suitable for typhoon-prone areas. The surface is treated with powder coating (film thickness 80-120μm) or fluorocarbon coating, achieving corrosion resistance that meets the AAMA 2605 standard and a service life of over 30 years.

Sound Insulation and Noise Reduction:

The multi-layer glass structure (such as laminated glass + double-glazed glass combination) combined with sealing strips provides noise reduction of 35-42dB, effectively blocking traffic noise and enhancing indoor tranquility.

4. Applicable Building Types

High-End Residences:

Villas, large apartments, and other projects utilize its large-size transparent design (single panel width up to 2000mm, height 3000mm) to create seamless indoor and outdoor spaces, enhancing the viewing experience.

Commercial Buildings:

Hotels, clubs, and other venues use its electric lifting function for intelligent management, while also reducing air conditioning energy consumption through efficient thermal insulation, meeting green building evaluation standards.

Public Facilities:

Buildings requiring large-span glass curtain walls, such as museums and exhibition halls, achieve structural and decorative integration through customized designs (such as curved and corner doors), balancing functionality and artistry.

5. Customization Options

Size and Shape:

Custom Aluminium Doors support non-standard size customization (minimum width 600mm, maximum height 3500mm), and can be made into curved, trapezoidal, or irregularly shaped door panels to adapt to complex building facades.

Surface Treatment:

Provides over 20 surface effects, including wood grain transfer printing (such as walnut and oak grain), metal brushing (champagne gold, titanium gray), and imitation stone textures, to match different decoration styles.

Glass Configuration:

Optional single/double silver Low-E glass, laminated safety glass, electrochromic glass, or smart dimming glass are available to achieve privacy protection, UV filtering, and energy-saving dimming functions.

Smart Integration:

Add rain and wind sensors, fingerprint locks, facial recognition systems, or integrate with smart home platforms to achieve remote control, automatic opening and closing, and security alerts.

Hardware Accessories:

Provides hardware from brands such as German ROTO, SIEGENIA, or domestic Jianlang, supporting multi-point locking, anti-pry alarms, and child safety locks, enhancing safety and convenience.
