Extruded Plastic Pvc Casement Windows Profile

$45-85 /Square Meter

Variety	Basement Windows
Contact Now

Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,FAS,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: shenzhen

Description

Product Attributes

Model No.: WD-PCW0022

Brand: Wendou

Warranty Service: More Than 5 Years

Place Of Origin: China

Material: Pvc

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: Made in China

Supply Ability: 10000㎡/ per month

Certificate: NFRC/CE/AS2047

HS Code: 7610100000

Port: shenzhen

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF,FAS,EXW

Product Description

1. Appearance Features: Minimalist Aesthetics and Diverse Colors

Extruded Plastic PVC Casement Windows Profiles feature clean, flowing lines and a modern design. The extrusion process achieves precise molding, resulting in a smooth, seamless surface and a unified visual effect. A rich selection of colors is available, including classic shades such as white, coffee, and walnut. Two-tone co-extrusion or lamination processes are supported to achieve dual-tone effects, meeting the needs of various architectural styles. For example, light colors suit modern minimalist styles, while dark wood grain complements antique or natural styles. Furthermore, the profile surface can be mirror-polished or matte-finished, enhancing both texture and scratch resistance.

2. PVC Windows Structural Advantages: Multi-Cavity Design and Functional Integration

Multi-Cavity Structure: Mainstream profiles employ a 3-7 cavity design, with independent chambers separating airflow, significantly improving thermal insulation performance. For example, the 3-cavity structure of the 60mm series profiles reduces the thermal conductivity coefficient, while the 5-cavity structure of the 65mm series further optimizes energy loss, making them suitable for cold regions or buildings with high energy efficiency requirements.

Drainage and Sealing System: Built-in independent drainage chambers and pressure-balanced channels prevent rainwater backflow; combined with EPDM rubber sealing strips, a triple-layer sealing system provides airtightness, watertightness, and sound insulation. Some high-end models also feature concealed drainage holes, balancing functionality and aesthetics.

Steel Lining Reinforced Design: Large steel lining cavities are embedded with galvanized steel linings, enhancing the profile's wind pressure resistance and ensuring safety in high-rise buildings or typhoon-prone areas. The steel lining shape precisely matches the profile's internal cavity, preventing deformation and extending service life.

Glass Installation Flexibility: Configuration with different sized pressure strip grooves supports the installation of single-pane, double-pane, or triple-pane laminated glass, meeting diverse needs such as sound insulation, heat insulation, and explosion protection.

3. Material Characteristics: Balancing Durability and Environmental Friendliness

UPVC Material: PVC Profile Windows are primarily made of unplasticized polyvinyl chloride (UPVC), possessing excellent weather resistance, corrosion resistance, and fire resistance (fire rating up to B1). Its strong chemical stability resists UV radiation and acid rain erosion, and it does not fade or crack with long-term use.

Environmentally Friendly Formula: Utilizing calcium-zinc stabilizers instead of traditional lead salt stabilizers reduces heavy metal pollution and complies with EU RoHS environmental standards. Some manufacturers have obtained ISO9001 quality management system certification, ensuring the material is non-toxic, harmless, and directly recyclable.

Lightweight and High-Strength: Compared to aluminum alloy profiles, PVC profiles have a lower density (approximately 1.4 g/cm³), reducing building load; simultaneously, through a multi-cavity structure and steel reinforcement, a balance between lightweight and high strength is achieved, significantly improving impact resistance.

4. Application Scenarios: Comprehensive Coverage from Residential to Commercial Spaces

Residential Sector: Widely used in apartments, villas, and other residential settings, especially suitable for bedrooms and studies requiring efficient sound and heat insulation. Its outward-opening design maximizes ventilation area, and when paired with a screen, it keeps out insects and enhances living comfort.

Commercial Buildings: In office buildings, hotels, schools, and other locations, PVC casement windows are the preferred choice due to their low maintenance costs and long lifespan. Their multi-cavity structure effectively reduces air conditioning energy consumption, meeting green building standards; the sealed design reduces noise interference, creating a quiet office environment with Soundproof PVC windows.

Special Environments: In cold regions, the combination of multi-cavity structures and triple-glazed windows achieves an extremely low U-value (thermal conductivity), reducing heat loss; in coastal or high-humidity areas, the corrosion resistance of UPVC ensures the profiles are not affected by salt spray, extending their service life.

Renovation Projects: In old window renovations, PVC profiles can directly replace existing wooden or steel windows without large-scale structural adjustments, reducing renovation costs and construction time.
