American Style Sliding Upvc Windows Frames With Glass

American Style Sliding Upvc Windows Frames With Glass

$45-85 /

Variety	Sliding Windows
Contact Now

Min. Order: 1
Transportation: Ocean
Port: shenzhen

Description

Product Attributes

Model No.: WD-PVCS024

Brand: Wendou

Warranty Service: More Than 5 Years

Place Of Origin: China

Material: Pvc

Packaging & Delivery

Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: Made in China

Supply Ability: 10000㎡/ per month

Certificate: NFRC/CE/AS2047

HS Code: 7610100000

Port: shenzhen

Product Description

American Style Sliding UPVC Windows Frames With Glass

1. Core Advantages of PVC Sliding Windows

High Space Utilization:Vertical sliding design (such as a single lift-up window) eliminates the need for outward or inward opening space, making it suitable for small apartments or narrow areas. The opening area is flexible and controllable, improving ventilation efficiency by over 30%.

Superior Sealing Performance:Multi-chamber profiles combined with multiple sealing strips achieve an airtightness of level 6 (international standard), a watertightness of level 4, and a wind pressure resistance of level 9 (e.g., a certain brand's wind pressure resistance value is 4.0≤P3<4.5kPa), effectively resisting typhoons and heavy rain.

Significant Energy Saving:Double-glazed windows (such as 5mm+9A+5mm) filled with argon gas, combined with the low thermal conductivity of UPVC (0.16W/m·K), result in an overall U-value as low as 1.8W/(m²·K), reducing air conditioning energy consumption by 20%-30%. Upgraded Safety Protection: Features built-in steel reinforcement (1.2mm-2.5mm thick) and anti-pry locking points; some models are equipped with child safety locks and fall arrestors, meeting EU EN1279 safety standards.

2. PVC Profile Windows Material Characteristics

UPVC Profiles: Made of unplasticized polyvinyl chloride (UPVC), highly weather-resistant (no deformation under temperature differences from -30℃ to 70℃), resistant to UV aging, with a service life of over 25 years, and 100% recyclable, meeting LEED certification requirements for green building.

Flexible Glass Configurations: Supports single-pane (5mm-12mm), double-pane (5mm+9A+5mm to 5mm+28A+5mm), triple-pane (5mm+12A+5mm+12A+5mm), Low-E glass, laminated glass, etc., meeting requirements for sound insulation (noise reduction of over 35dB), heat insulation, and explosion protection.

Steel-lined reinforced structure: Built-in galvanized steel lining cavity enhances wind pressure resistance, ensuring safety in high-rise buildings or coastal areas. Some brands offer a steel lining thickness of up to 2.5mm, exceeding industry standards.

Environmentally friendly formula: Uses calcium-zinc stabilizers instead of lead salt stabilizers, reducing heavy metal pollution. The material has a recyclability rate of up to 90%, supporting carbon neutrality goals.

3. PVC Windows Application Scenarios

Residential Sector: Suitable for villas, apartments, townhouses, etc., especially ideal for areas requiring efficient ventilation and waterproofing/moisture control, such as kitchens, bathrooms, and balconies. The vertical sliding design avoids interference with curtains or cabinets, improving space utilization.

Commercial Buildings: In office buildings, hotels, schools, etc., its low maintenance costs (no painting or rust prevention required) and long lifespan make it a top choice. The sealed design reduces air conditioning energy consumption, meeting green building evaluation standards.

Special Environments: In coastal areas, the corrosion resistance of UPVC ensures the profiles are protected from salt spray corrosion; in cold regions, the combination of multi-layered cavities and Low-E glass reduces heat loss; in high-rise buildings, wind pressure resistance and fall arrestors ensure safety.

4. Customization Options

Size and Shape Customization: Non-standard sizes are supported, adapting to irregularly shaped windows or special building structures, such as arched windows, corner windows, and trapezoidal windows. The minimum width can be compressed to 400mm, and the maximum height can reach 3000mm.

Glass and Screen Configurations: A variety of options are available, including single-glass Low-E, double-glass Low-E, laminated glass, and triple-glazed double-cavity glass; screens are available in magnetic, folding, or retractable styles, with materials including 304 stainless steel, fiberglass, or nylon, meeting both insect protection and ventilation needs.

Hardware System Upgrades: Optional smart security devices such as multi-point locks, fingerprint locks, and remote control locks are available, or upgrades can be made to concealed handles and silent sliding rails, enhancing security and ease of use.

Colors and Surface Treatments: Available in basic colors such as pure white, matte gray, space gray, and coffee, and supports two-color co-extrusion processes (such as gray exterior and wood interior) to suit different architectural styles; surface treatments include powder coating, wood grain transfer, and fluorocarbon spraying to enhance texture and weather resistance.
