Aluminum Facade for Commercial Office Spaces

Aluminum Facade for Commercial Office Spaces

$75-150 /Square Meter

Material	Aluminum
option
Contact Now

Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 1 Square Meter
Transportation: Ocean
Port: Shenzhen

Description

Product Attributes

Model No.: WD-CWL007

Brand: Wendou

Variety: Curtain Walls

After-sales Service: Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection, Return And Replacement

Application Scenario: Hotel, Apartment, Villa, Leisure Facilities, Sports Venues, Courtyard, Farmhouse, Kitchen, Supermarket, Warehouse, Hospital, Mall, Office Building, Exterior, Hall

Place Of Origin: China

Screen Netting Material: Aluminum Alloy/Stainless steel/Fiberglass

Main Material: Aluminum alloy+Glass+Accessories

Glass: Tempered glazing+Laminated glazing+Low-E glazing+Reflective glazing+Frosted glazing

Color: Customized based on your needs

Hardware: Germany brand/Chinese brand/American brand

Packaging & Delivery

Selling Units:	Square Meter
Package Type:	Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate
Picture Example:

Supply Ability & Additional Information

Packaging: Adhesive protective film+Bubber film+Hardboard+Strechable plastic wrap+Non-fumigation plywood-crate

Productivity: 150000㎡/year

Transportation: Ocean

Place of Origin: Made in China

Supply Ability: 10000㎡/M

Certificate: NFRC/CE/AS2047

HS Code: 7610100000

Port: Shenzhen

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF,EXW

Product Description

Aluminum Facade for Commercial Office Spaces is a building envelope structure with aluminum alloy profiles as the skeleton and aluminum plates or glass as the panels, which is specially designed for office scenes.

Core features

Lightweight and high strength: The density of aluminum alloy is 2.7g/cm³, which is only 1/3 of that of steel, greatly reducing the building load. For example, a 3mm thick aluminum plate weighs about 8kg per square meter, which is more than 70% lighter than traditional stone curtain walls.

Energy-saving and high efficiency: The heat transfer coefficient (K value) of the broken bridge aluminum profile combined with hollow Low-E glass can be as low as 1.2W/(m²·K), which is more than 30% energy-saving compared with ordinary curtain walls.

Flexible design: It supports a variety of shapes such as planes, curved surfaces, and special shapes to meet the needs of architectural aesthetics. For example, the Sydney 200 George Street project uses parametric customized aluminum plates to achieve complex geometric facade effects.

Strong durability: Fluorocarbon sprayed aluminum plates have weather resistance of more than 25 years, excellent UV resistance and corrosion resistance, and low maintenance costs.

Application scenarios

Aluminum curtain walls are widely used in commercial office spaces, with typical cases including:

High-rise office buildings: such as the Shanghai Tower, which uses a unitized Aluminum Curtain Wall system with a wind pressure resistance of 5.0kPa, meeting the safety requirements of super-high-rise buildings.

Headquarters buildings: such as Alibaba's Xixi Park, which achieves a balance between natural lighting and heat insulation through a combination of aluminum panels and glass curtain walls, reducing air conditioning energy consumption by 20%.

Creative office spaces: such as SOHO Fuxing Plaza, which uses foam aluminum panels to create a lobby space that absorbs and reduces noise, with an opening rate of 30% and a sound absorption coefficient of 0.6 (500Hz), creating a healthy and green office environment.

Supporting components

Aluminum Windows For Curtain Wall

Using broken bridge insulation profiles, air tightness reaches level 8 (the highest level of national standards), water tightness ≥700Pa, and wind pressure resistance ≥5.0kPa. For example, the curtain wall windows of the Hong Kong ICC Building account for 15% of the opening sashes, taking into account both ventilation and safety.

Aluminum Frames For Curtain Wall

It consists of columns, beams, and adapters, and the wall thickness of the profile is ≥3mm (national standard requirement). The cross section is optimized through finite element analysis, which can withstand a 12-level typhoon (wind speed ≥32.7m/s) to ensure structural safety.

Curtain Wall Aluminum

Commonly used 6063-T5/T6 alloy, tensile strength ≥205MPa, yield strength ≥175MPa. Surface treatment includes anodizing (film thickness ≥15μm) and fluorocarbon spraying (film thickness ≥40μm), meeting 25-year weather resistance requirements.

Industry Trends and Data

Modular design: Unitized aluminum curtain wall systems occupy 67.8% of the global market share, factory-prefabricated unit panels, on-site installation efficiency increased by 50%, and construction period shortened by 30%.

Intelligent integration: For example, Lindner aluminum panel curtain wall integrates photovoltaic glass and sensors to realize power generation and self-monitoring functions, and the annual power generation per square meter can reach 150kWh.

Green building materials: The recycling rate of aluminum alloy is greater than 95%, and carbon emissions are 40% lower than traditional materials. For example, Dubai Museum of the Future uses 100% recycled aluminum profiles to help achieve carbon neutrality in buildings.
